Matrix Prime Entry Level Gigabit IP Phone

SPARSH VP210

  • 128*64 Graphical LCD
  • 4 Context Sensitive Keys
  • Intuitive User Interface with Icon
  • Full-duplex Hands-free Speakerphone with AEC
  • Power on Ethernet
  • Dimension (mm): Length 163 x Breadth 210 x Height 61.5

Description

IP-Phones have changed how we communicate in our personal and professional lives. This ever-evolving device plays a critical role in the profitability of corporates.

SPARSH VP210 offers a range of applications for offices like call centers, enterprises, small businesses, branch offices, and government sectors. Designed to maximize the reach and accessibility of an organization, this device boosts organizations’ productivity.

This Gigabit IP Phone is the entry-level phone in the family of SIP phones and comes with 50+ advanced calling features to provide a seamless and secure communication solution.

SPECIFICATIONS

Parameters Specifications
Audio Features
  • Codec: G.722, G.711(A/µ), G.729,
  • G.726, G.723
  • DTMF: In-band, Out-of-band (RFC 2833) and
  • SIP INFO
  • Full-duplex hands-free speakerphone with
  • AEC
  • VAD, CNG, AEC, AJB, AGC
Phone Features
  • Abbreviated Dialing, Call Pick Up and Internal Call Restriction
  • Call Hold, Mute and DND
  • One-touch Transfer and Hotline
  • Redial, Auto Call Back (ACB) and Auto Answer
  • Call Forward, Call Waiting and Call Transfer
  • 3-way Conferencing and Conference Multi-party
  • Emergency Call and Conferencing
Display
  • 128 x 64 Graphical LCD
  • LED for Call, Message Wait Indication
  • Intuitive user interface with Icon
Networking and Security
  • Extended (Proprietary) SIP
  • Protocol
  • IP assignment: Static, DHCP
  • SRTP
  • TLS
  • QoS: 802.1p/Q tagging (VLAN)
Physical Features
  • Desk mount
  • External AC Adaptor:
  • AC 100~240V Input & DC 5V/600mA output
  • Operating humidity: 10 ~ 95%
  • Operating temperature: 0 ~ 45 °C
  • Dimension (W x D x H): 63 x210 x 61.5 mm
Installation Desk mount
Environmental
Operating Temperature 0° C to 45°C
Operating Humidity 10 – 95% (Non-condensing)
Certifications CE, FCC-15 (Class B), RoHS

DOWNLOADS

       Datasheet
